Up to 5X Faster with Dual-Radio 3x3 11AC MIMO Technology
The UniFi AC Pro AP supports simultaneous dual-band, 3×3 MIMO technology in the 5 and 2.4 GHz radio bands.
Designed for Optimal RF Performance
The newly redesigned UniFi Controller optimizes RF performance:
Versatile Design
The UniFi AC Pro AP is a gigabit, 802.3af-powered access point suitable for indoor or outdoor use.
Scalable Enterprise Wi-Fi Management
The UniFi Controller v5 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
Model Comparison
Product Name
Dimensions
Environment
2.4 GHz Speed
5 GHz Speed
PoE Mode
Ports
UAP-AC-LITE
∅160 x 31.45 mm
Indoor
300 Mbps
867 Mbps
802.3af/A PoE & 24V PoE
(1) 10/100/1000 Ethernet
UAP-AC-LR
∅175.7 x 43.2 mm
Indoor
450 Mbps
867 Mbps
802.3af/A PoE & 24V PoE
(1) 10/100/1000 Ethernet
UAP-AC-PRO
∅196.7 x 35 mm
Indoor/Outdoor
450 Mbps
1300 Mbps
802.3af PoE/802.3at PoE+
(2) 10/100/1000 Ethernet
UAP-AC-EDU
∅287.5 x 125.9 mm
Indoor
300 Mbps
1300 Mbps
802.3at PoE+
(1) 10/100/1000 Ethernet
UAP-HD
∅220 x 48.1 mm
Indoor/Outdoor
800 Mbps
1733 Mbps
802.3at PoE+
(2) 10/100/1000 Ethernet
